Pushbutton

A push button switch is an electro-mechanical device that is activated by a press on the button. Operators can push the button to turn on (initiate) or off (break) the electrical circuit of an equipment. Momentary (non-latching) and maintained (latching) actions are the two mechanisms used in push button switches.

Lumex push button switches have a variety of features to meet all kinds of customer requirements. A wide range of panel cutouts is available: Ø12mm, Ø16mm, Ø19mm, and Ø22mm. At Lumex, you can always find complete switch features to match your application. Key features include momentary function, maintained function, solder terminal, PC terminal, wire leads, gold contacts, waterproof (IP67), vandal-resistant (IK10), plastic housing, metal housing, electro-mechanical, bushing mounting, snap-in mounting, high current, and UL certified, among others.

Key Features

Size(Panal Cutout Diameter)：

Lumex offer pushbutton switches for panel cutout diameter ɸ12mm, ɸ16mm, ɸ19mm and ɸ22mm. Besides those parts, customization are available for bigger size, waterproof IP67, indication by led, wire harness and sealing service.

Material：

A typical material for pushbutton is metal and plastic. Metal, zinc alloy, stainless steel, and aluminum are used in all series and different panel cutouts. Plastic can be found in panel cutout diameter ɸ12mm and ɸ16mm.

Current Rating：

One of the many important characteristics of the pushbutton switch is the current rating. Lumex provides mA, 2A, 5A, and 10A for all panel cutouts. The current rating 10A is not available in ɸ12mm.
